Piezo Switches
ATEX
16mm ø
19mm ø
22mm ø
30mm ø
ATEX
Piezo ATEX Switches
16MM Ø
PBA Series – ATEX
R1 – Flat Actuator
R5 – Flat Actuator with finger location (non-illuminated only)
Function: Pulse N/O
Materials: 316L Stainless Steel
Connectors: Flying leads
Sealing: IP66
R5 – Flat Actuator with finger location (non-illuminated only)
Function: Pulse N/O
Materials: 316L Stainless Steel
Connectors: Flying leads
Sealing: IP66
19MM Ø
PBA Series – ATEX
R9 – Flat Actuator
Function: Pulse N/O
Materials: 316L Stainless Steel
Connectors: Flying leads
Sealing: IP66
Function: Pulse N/O
Materials: 316L Stainless Steel
Connectors: Flying leads
Sealing: IP66
22MM Ø
PBA Series – ATEX
R2 – Flat Actuator
R6 – Flat Actuator with finger location
(R2 and R6 not available with illuminated ring.)
Function: Pulse N/O
Materials: 316L Stainless Steel
Connectors: Flying leads
Sealing: IP66
R6 – Flat Actuator with finger location
(R2 and R6 not available with illuminated ring.)
Function: Pulse N/O
Materials: 316L Stainless Steel
Connectors: Flying leads
Sealing: IP66
16mm ø
16mm Ø Piezo Anti-Vandal Switches
PBA Series
R1 – Flat Operator, 4.5mm Height
T5 – Flat Operator, 1mm Height – Non-Illuminated
R5 – Flat Operator with Finger Locator, 4.5mm Height – Non-Illuminated
Function: Pulse N/O, N/C or ON/OFF*
Materials: Aluminium or 316L Stainless Steel
Connectors: Flying leads, Cable or Straight PC (T5 model, non-illuminated, functions A & B only)
Electrical Function:
Function A – standard 200 mA 24 VAC/DC – option 1 A 24 VAC/DC
Function B – standard 100 mA 24 VAC/DC
* (requires external power supply – cannot be combined with T5 operator – illumination type W only)
T5 – Flat Operator, 1mm Height – Non-Illuminated
R5 – Flat Operator with Finger Locator, 4.5mm Height – Non-Illuminated
Function: Pulse N/O, N/C or ON/OFF*
Materials: Aluminium or 316L Stainless Steel
Connectors: Flying leads, Cable or Straight PC (T5 model, non-illuminated, functions A & B only)
Electrical Function:
Function A – standard 200 mA 24 VAC/DC – option 1 A 24 VAC/DC
Function B – standard 100 mA 24 VAC/DC
* (requires external power supply – cannot be combined with T5 operator – illumination type W only)
19mm ø
19mm Ø Piezo Anti-Vandal Switches
PBA Series
R9 – Flat Operator, 3mm Height
RA – Flat Operator with Chamfer, 3mm Height
Function: Pulse N/O, N/C or ON/OFF*
Materials: Aluminium or 316L Stainless Steel
Connectors: Flying leads, Cable or Straight PC
Electrical Function:
Function A – standard 200 mA 24 VAC/DC – option 1 A 24 VAC/DC
Function B – standard 100 mA 24 VAC/DC
* (requires external power supply – illumination type W only)
RA – Flat Operator with Chamfer, 3mm Height
Function: Pulse N/O, N/C or ON/OFF*
Materials: Aluminium or 316L Stainless Steel
Connectors: Flying leads, Cable or Straight PC
Electrical Function:
Function A – standard 200 mA 24 VAC/DC – option 1 A 24 VAC/DC
Function B – standard 100 mA 24 VAC/DC
* (requires external power supply – illumination type W only)
22mm ø
22mm Ø Piezo Anti-Vandal Switches
PBA Series
R2 – Flat Operator, 3mm height
R6 – Flat Operator with finger location, 3mm height – Not available with illuminated ring.
RY – Flat Operator with chamfer, operator 4.5 mm height, Available with thin or large illuminated ring only
RZ – Flat Operator, 4.5 mm height, Available with thin or large illuminated ring only
Function: Pulse N/O, N/C or ON/OFF*
Materials: Aluminium or 316L Stainless Steel
Connectors: Flying leads or Cable
Electrical Function:
Function A – standard 200 mA 24 VAC/DC – option 1 A 24 VAC/DC
Function B – standard 100 mA 24 VAC/DC
* (requires external power supply – Illumination types V, Y and Z only – only one LED colour)
R6 – Flat Operator with finger location, 3mm height – Not available with illuminated ring.
RY – Flat Operator with chamfer, operator 4.5 mm height, Available with thin or large illuminated ring only
RZ – Flat Operator, 4.5 mm height, Available with thin or large illuminated ring only
Function: Pulse N/O, N/C or ON/OFF*
Materials: Aluminium or 316L Stainless Steel
Connectors: Flying leads or Cable
Electrical Function:
Function A – standard 200 mA 24 VAC/DC – option 1 A 24 VAC/DC
Function B – standard 100 mA 24 VAC/DC
* (requires external power supply – Illumination types V, Y and Z only – only one LED colour)
30mm ø
30mm Ø Piezo Anti-Vandal Switches
PBA Series
M1 – Flat Operator, 2.5mm Height – Non-Illuminated
M2 – Flat Operator, 2.5mm Height – Illuminated, flush translucent ring
M3 – Flat Operator 2.5mm Height – Illuminated, flush colored ring (same color as LED)
M4 – Flat Operator 5.5mm Height – Illuminated, prominent translucent ring
M5 – Flat Operator 5.5mm Height – Illuminated, prominent colored ring (same color as LED)
Function: Pulse N/O
Materials: Aluminium or 316L Stainless Steel Connectors: Flying leads or Cable
Electrical Function: 1A 24 VAC/DC
M2 – Flat Operator, 2.5mm Height – Illuminated, flush translucent ring
M3 – Flat Operator 2.5mm Height – Illuminated, flush colored ring (same color as LED)
M4 – Flat Operator 5.5mm Height – Illuminated, prominent translucent ring
M5 – Flat Operator 5.5mm Height – Illuminated, prominent colored ring (same color as LED)
Function: Pulse N/O
Materials: Aluminium or 316L Stainless Steel Connectors: Flying leads or Cable
Electrical Function: 1A 24 VAC/DC
